Automation control QXY series steel plate line
Product introduction
QXY series steel plate pretreat line is designed by our engineer which lesson advantages of similar product from both within the country and abroad. The rusting clean part (shot blast cleaning)adopts high – efficient blast wheel and full shutter type shot sand separator. The sweeping machine adopts specially made high-strength nylon rolling brush and high – pressure ventilator. The preheating and drying part adopt various heating methods. The paint spraying part adopt high-pressure airless spraying method. The complete set of equipment is controlled by PLC, and is the large-size complete equipment of international advanced level.
It is mainly used for surface treatment(namely preheating ,rust removal, paint spraying and drying)of steel plate and various structural sections, as well as for cleaning and strengthening of metal structure parts.
Product specification
No | Item Model | Type | |||||||
QXY2000 QXY2200 QXY2500 | QXY3000 QXY3200 QXY3500 | QXY3500 QXY4000 QXY4500 | QXY5000 QXY5500 QXY6000 | ||||||
1 | Steel plate | Width | mm | 2000/2200/2500 | 3000/3200/3500 | 3500/4000/4500 | 5000/5500/6000 | ||
Thickness | mm | 3~150 | |||||||
Frame member | Height | mm | 400~800 | ||||||
2 | Workpiece delivery speed | m/min | 0~6 | 0~6 | 0~6 | 0~6 | |||
Derusting grade | ISO8501-1,1988 or GB8923-88 A-B Sa2.5 | ||||||||
3 | Surface roughness | μm | 30~75 | ||||||
4 | Film thickness | μm | 15~25 | ||||||
6 | Installed powder | Kw | ~415 | ~615 | ~850 | ~1050 | |||
7 | Compressed air consumption | m³/h | 3~4 | ||||||
8 | Compressed air pressure range | Mpa | 0.5~0.6 | ||||||
9 | Abrasive initial filling | mm | 8~10 | 12~16 | 15~20 | ||||
